2 Notes on the Product
2.1 Product identification
These instructions apply to the following radar distance sensors:
DR 15 S – M30 E – IOL 8 X2 – H1 1 4 1
DR 15 S
Series
–
Aperture angle, radar wave
S 7°
Sensing range
… Max. range in m
Functional principle
DR Radar, Distance
M30 E
Design
–
Housing length
E Long
Housing
M… Threaded barrel, stain-
less steel
Ø in [mm]
IOL 8 X2
Electrical version
–
Indication
X2 Multicolor LED
Voltage range
8 17…33 VDC
Output function
2UPN Switching outputs
IOL IO-Link
H1 1 4 1
Electrical connection:
Connector
Assignment
1 Standard assignment
Number of contacts
4 4 contacts
Connector type
1 Straight
Connector type
H1 M12 × 1 connector
2.2 Scope of delivery
n Radar distance sensor
n Two M30 threaded nuts for mounting
n Quick Start Guide
2.3 Turck service
Turck supports you with your projects, from initial analysis to the commissioning of your applic-
ation. The Turck product database under www.turck.com contains software tools for program-
ming, configuration or commissioning, data sheets and CAD files in numerous export formats.
The contact details of Turck subsidiaries worldwide can be found on p. [}31].
