V01.00 | 2021/11
29
14 Technical Data
Type DR15S-M30E-IOL8X2-H1141 DR15S-M30E-2UPN8X2-H1141
ID 100030148 100030149
Radar data
Frequency range 122…123 GHz
Range 350…15000 mm
Resolution 1 mm
Minimum value – measuring
range
500 mm
Minimum value – switching
range
50 mm
Linearity tolerance ≤ ± 0.1 %
Edge length of the norm target 100 mm
EIRP radiant power 10 dBm
EIRP radiant power 20 dBm
Opening angle 15°
Repetition accuracy 2 mm
Hysteresis ≤ 50 mm
Electrical data
Operating voltage 17…33 VDC
Ripple < 10 % U
ss
DC rated operational current ≤ 250 mA
No-load current ≤ 100 mA
Residual current ≤ 0.1 mA
Short-circuit protection Yes/cyclic
Reverse polarity protection Yes
Communication protocol IO-Link
Output function NC/NO programmable, PNP/
NPN, analog output
NC/NO programmable, PNP/
NPN
Output 2 Analog output Switching output
Current output 4…20 mA –
Voltage output 0…10 V –
Load resistance current output ≤ 0.5 kΩ –
Load resistance voltage output ≥ 8 kΩ –
Voltage drop at I
e
≤ 2 V
Switching frequency ≤ 10 Hz
Readiness delay ≤ 450 ms
Response time, typically < 10 ms
IO-Link
IO-Link specification V1.1
IO-Link port type Class A
Communication mode COM 2 (38.4 kBaud)
Process data width 32-bit
