Technical Data
30
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Type DR15S-M30E-IOL8X2-H1141 DR15S-M30E-2UPN8X2-H1141
Measured value information 28-bit
Switching point information 2-bit
Frame type 2.2
Minimum cycle time 3 ms
Function Pin 4 IO-Link
Function Pin 2 Analog DI
Maximum cable length 20 m
Profile support Smart Sensor Profile
Mechanical data
Design Threaded barrel, M30E
Dimensions Ø 44.7 × 104.3 mm
Housing material Stainless steel, 1.4401 (AISI 316)
PTFE
Max. tightening torque of
housing nuts
75 Nm
Electrical connection Male connector, M12 × 1
Ambient temperature -25…+65 °C
Storage temperature -40…+85 °C
Protection type IP67, IP69K (UL: Type 1)
Operating voltage indication LED, green
Switching state indication 2-color LED, yellow
Vibration resistance 20 g (10…2000 Hz), EN 60068-2-6
Shock testing EN 60068-2-27
Shock resistance 100 g (11 ms)
EMC EN 61000-6-2:2019
ETSI EN 301489-3 v.1.6.1
Approvals CE, UKCA, ETSI, FCC, UL
