Teaching the Reference Positions
Limax Safe
Setup
Arrive at this screen from
Checklist > Hoist Group
View Events
Out of Service
Checklist >Limax Safe Setup
Follow on screen prompts to setup the shaft reference points for Limax33CP shaft encoder and safety device.
Back
Fri 03/09/21 15:47:00
?
Help
Teach Bottom
Reference Position
34567 mm
9780 mm
Instructions:
1) To Commission - Switch to Panel Test, then
activate Teach Mode and then Teach Top and
Bottom Reference Positions.
Limit offsets can be modified whilst on
Prepare to Test and Doors Disabled.
Enable
Doors
End
Teach
Mode
Teach Top
Reference Position
Limax Position 10051 mm
Door Zone
Length
500 mm
Top Final Limit
Offset
500 mm
Bottom Final Limit
Offset
200 mm
Top Inspection
Limit Offset
200 mm
Bottom Inspection
Limit Offset
Enable
Settings
Mode
System
Reset
4.000 m/s
Trip Test Speed
Prepare to
Test
Door Zone
Length RL
=Level 1
Factory
Config.
Teach mode – To Teach / Learn the Top and Bottom Reference Positions.
Limax Teach will only work if the following conditions are met:
1) In Emergency Electrical Operation (Panel Test - PTR Input Active).
Sequence of Teach Operation:
1) Select “Limax Safe Setup” from checklist.
2) Place car on “Door Disable”
3) Press the “System Reset” button wait 20 seconds for the Limax to re-boot.
4) Place in “Teach Mode” with the Enable Teach button.
5) Using the panel test pushes - Move car to top of the shaft so the counterweight is on the buffers.
6) Press teach top reference position.
7) Using the panel test pushes - Move car to bottom of the shaft so the car is on the buffers.
8) Press teach bottom reference position.
9) Move car to bottom floor level.
10) Press “End Teach Mode” to activate the Limax3CP.
During teach mode event code 300 "Limax3CP Teach Mode" is logged.
Once the upper and lower reference positions are taught the lift can be switched to inspection control.
Limit buttons
Displays distance of the Top final Limit with respect to the Top Reference Position, this can be
adjusted in settings mode.
Displays distance of the Bottom Top final Limit with respect to the Bottom Reference Position,
again this can be adjusted.
