Displays distance of the Top Inspection Limit with respect to the Top Reference Position or Upper
Stopping System point if the EN81-21 setting is active for lifts with reduced head room.
Displays distance of the Bottom Inspection Limit with respect to the Bottom Reference Position or
Lower Stopping System point if EN81-21 setting is active for lifts with reduced pit depth.
Displays the speed at which the testing of the Limax overspeed feature is carried out at. This
does not affect the actual overspeed tripping in normal operation, just gives the ability to test the feature at a lower
speed.
Reset and Factory Config buttons
Press this to send the unit a reset command, this will reboot the device.
Wait 20 seconds for the unit to re-boot before sending other commands.
Press to bring up the factory configured settings.
Note these cannot be modified without returning the unit to TVC.
