This test proves the pre-trigger inspection stopping points that are used in case of reduced headroom in the pit and
car top escape spaces, see EN81-21. Test is carried out in normal with Door Disable set.
The pre-trigger inspection stopping points can be tested by selecting the “Pre Trig Test” once in Test mode. Move
the car to a terminal floor by placing a top or bottom call. The Limax should trip at the point the pre-trigger stopping
points are set. This will be carried out at inspection speed.
Limax SR1 UCM Test
The SR1 UCM Test allows the SR1 turn off command to be disabled for 10 seconds. This allows the car to leave the
floor by placing a car call with SR1 still turned on, thus testing the Limax3CP UCM feature. The Limax3CP will trip
with the unintended movement fault.
Limax Output Testing
The OC / SR1 and eSGC outputs can be tested / toggled by pressing the relevant buttons.
These tests only work when the car is stationary. An event code 303 "Limax3CP OC Contact Open” is logged
during the OC test this can be reset in the solutions screen.
Additional screen info buttons
Displays Current Mode, Pre-Com, Teach, Normal, Settings or Test and sub modes.
Shown in orange if there is an active fault from the Limax unit.
Fault Description
The active faults are scrolled here.
Shows IO from the Limax unit, see manual.
This shows the units config CRC, if this is red it does not match the Ethos Two’s
CRC and speed will be limited to dive speed. The CRC is factory set in both the Ethos Two and the
Limax unit.
If a fault is active or the CRCs don’t match the event code 302 "SE Limax3CP Fault or Error" is logged.
Additional screen function buttons
Enable
Doors
Shortcut for disabling doors, test and teach mode will not work unless DDS is active.
Press this button to clear certain active Limax faults.
Press this to send the unit a reset command, this will reboot the device.
Background Limax Services
Limax Reset Service
Twice a day the Ethos Two will send an OC test command to the Limax, this is done at the 1
st
and 2
nd
Limax reset
times. The times are configurable through the MMI. These are defaulted to 01:00 am and 02:00 am.
Twice a year a full reset is commanded. This happens on the 1
st
of January and the 1
st
of July.
When idle, the lift will shut its doors and then sit there for approx. 10 seconds whilst it resets, then the lift will go back
into service.
The test is also carried out when coming off inspection or emergency electrical operation.
