TYAN TS75-B8252 - Page 97

97
http://www.tyan.com
D4P_PW1 / D4P_PW2 / D4P_PW3: 4-pin Power Connector to HDD BP
Pin
1
2
3
4
Signal
P12V_IN
GND
GND
VCC5
PE_PW1: 8-pin Power Connector to HDD BP
Signal
Pin
Pin
Signal
GND
1
5
P12_HDD1
GND
2
6
P12_HDD1
GND
3
7
P12_HDD1
GND
4
8
P12_HDD1
PE_PW2: 8-pin Power Connector to HDD BP
Signal
Pin
Pin
Signal
GND
1
5
P12_HDD2
GND
2
6
P12_HDD2
GND
3
7
P12_HDD2
GND
4
8
P12_HDD2
PE_PW3: 8-pin Power Connector to HDD BP
Signal
Pin
Pin
Signal
GND
1
5
P12_HDD3
GND
2
6
P12_HDD3
GND
3
7
P12_HDD3
GND
4
8
P12_HDD3
NOTE: The 8-pin GPU power connector can support up to 20A.
PE_PW4: 8-pin Power Connector to GPU Card
Signal
Pin
Pin
Signal
GND
1
5
P12_GPU1
GND
2
6
P12_GPU1
GND
3
7
P12_GPU1
GND
4
8
P12_GPU1
