Tyco Electronics T200 IDENT - 2 Installation; Printer Overview

8 8
9
2.1 Printer Overview
1
2
3
4
5
6
7
8
1 Cover
2 Margin stops
3 Media roll retainer
4 Ribbon supply hub
5 Ribbon take-up hub
6 Roller
7 Print mechanics
8 Touchscreen display
Fig. 1 Printer with Tear-off Plate
9
9 Cutter or Perforator
Fig. 2 Printer with Cutter or Perforator
2 Installation
