DESCRIPTION OF TRACTOR CONTROLS
1
2
2 - 27
DANGER
If caught by the PTO shaft, a
severe injury or even death
can occur.
Stay out of the PTO shaft
while it is rotating.
When the PTO shaft is not
in use, place the cap over it.
Also, never remove the PTO
safety cover.
•
•
•
LOADER VALVE AND JOY-
STICK LEVER
The loader valve is installed under
the step on the right side and the
joystick lever is installed on the
right section in the cabin for easy
installation and operation of a
loader.
►
Abnormal operation of a loader
can lead to an accident. There-
fore, w h e n connecting the
hydraulic pipes, set the valve
connection according to the op-
erating directions specified on
the label attached to the joystick
lever.
•
WARNING
T57O208A
