Gauge/Page Menu ..
Select Gauges ..
MENU  Gauge/Page Menu ..  Select Gauges..
Used to select and assign gauges to pages and zones. See the sections; Gauge Pages and Zones and Gauge Zone
Assignments. Please also see the following: http://www.ultra-gauge.com/customer_support/knowledgebase.php?article=22
Page settings ..
MENU  Gauge/Page Menu ..  Page settings ..
Provides gauge page configuration settings
Unassign All Gauges
MENU  Gauge/Page Menu ..  Unassign All Gauges
Un-assigns all gauges from all pages and zones. Not commonly used. Can be used when it is desired to reassign all gauges.
Once unassigned the Main display will show no gauges.
Load Default Gauges
MENU  Gauge/Page Menu ..  Load Default Gauges
Restores the factory default Gauge assignments. When shipped UltraGauge has the following default gauge assignments:
Page Zone Gauge Page Zone Gauge
1
1 Instantaneous MPG
5
1 O2 Voltage Bank1 S1
2 Average MPG – General 2 O2 Voltage Bank2 S1
3 Instantaneous Gallons/Hour 3 O2 Voltage Bank1 S2
4 Fuel Level 4 O2 Voltage Bank2 S2
5 Time To Empty 5
Wide O2 λ Bank1 S1
6 Distance to Empty (DTE) 6
Wide O2 λ Bank2 S1
7 7
Wide O2 λ Bank1 S2
8 8
Wide O2 λ Bank2 S2
2
1 Boost Pressure 2 PSI
6
1 O2 Voltage Bank1 S1
2 Torque 1 ft.lbs 2 O2 Voltage Bank2 S1
3 Brake Horsepower 2 3 O2 Voltage Bank1 S2
4 Mass Air Flow 2 g/s 4 O2 Voltage Bank2 S2
5 Ave Gallons/Hr gen 5
Wide O2 λ Bank1 S1 .
6 Run Time gen 6
Wide O2 λ Bank2 S1 .
7 7
Wide O2 λ Bank1 S2 .
8 8
Wide O2 λ Bank2 S2 .
3
1 Srt Trip Ave MPG
7
1 Engine Oil Temp F
2 Srt Trip Ave G/H 2 Engine Oil Temp C
3 Srt Trip Gallons used 3 Fuel Injection Timing
4 Srt Trip Run Time 4 Exhaust Pressure PSI
5 Srt Trip Average MPH 5 Exhaust Pressure kPa
6 Srt Trip Miles 6 Charge Temp F
7 7 Charge Temp C
8 8 Boost Pressure PSI
4
1 UG Temperature F
2 Mass Air Flow 2 g/s
3 Engine Coolant Temperature
4 UG Temperature F
5 Oil Distance miles
6 Service Distance miles
7
8
