PAGES
Each of the seven pages can individually be enabled or disabled.
MENU Gauge/Page Menu ..
Select Gauge/Page .. Page settings ..
Page Enables
A disabled page will be skipped when the page is manually or auto advanced.
Each page can be configured to display 4, 6 or 8 Gauges.
MENU Gauge/Page Menu ..
Select Gauge/Page .. Page settings ..
Page Display Format
Any gauge can be assigned to any zone on any page. A gauge can be assigned to one or all pages. For example, RPM could be
assigned to zone 1 on all seven pages. A gauge can only be assigned once on any given page.
If enabled, the auto page advance feature will cycle through each enabled page.
MENU Gauge/Page Menu ..
Select Gauge/Page .. Page settings ..
Auto Page Advance
Pressing the “DOWN” key while auto-page is enabled, will cause the auto page feature to pause at the current page. Pressing
“DOWN” again will resume auto-page advance
The duration that a given page is displayed is configurable from 1-255 seconds. Each page can have a unique duration if
desired.
MENU Gauge/Page Menu ..
Select Gauge/Page .. Page settings ..
Auto Page Time
The Rate at which gauges are updated is configurable from 0.3 seconds to 2 seconds.
MENU Gauge/Page Menu ..
Select Gauge/Page .. Page settings ..
Page Refresh Time
The set Refresh time applies to every page. This setting also affects the rate at which the Heart Beat indicator beats. Lowering
the refresh time, increases the heart beat rate and the rate at which gauges are updated. This setting is intended for vehicles with
the CAN protocol and is not recommended for KWP and 9141 protocols.
GAUGE ZONE ASSIGNMENT
To assign a gauge to a page and zone:
1.
select
MENU Gauge/Page Menu ..
Select Gauge/Page .. Select Gauges
Select Page n Gauges
2. Use the UP & DOWN keys to Navigate to the desired Gauge. Press Next or Back to advance to the next group of gauges
3. While the cursor is positioned next to the desired gauge, Press MENU. This will cause the cursor to blink.
4. Pressing UP or DOWN will cause the Cursor to change to a number corresponding to Zones 1-8. You may also continue to
hold UP or DOWN and the zones will advance automatically.
5. When the desired Zone is displayed, Press MENU to assign the Gauge to that Zone. Once assigned the cursor will stop
blinking. It is not necessary to first individually unassign a gauge by changing from a zone number to “blank”, before making a
new assignment.
6. Repeat the operation for each desired Gauge.
Once a gauge has been assigned to a zone, it is saved. The UltraGauge configuration is stored in non-volatile memory so that it is
preserved through car start/stop cycles or when the unit is unplugged. The configuration remains until changed.
All the gauges can be unassigned, with the menu item:
MENU
Gauge/Page Menu ..
Select Gauge/Page ..
Unassign All Gauges.
Once unassigned the Main Gauge screen will show no gauges, and will only show the loop indicator and heartbeat and the text: “No
Gauges Selected”. This will be true for each gauge page set to display 4 or 6 gauges. This will also be true on a gauge page basis if all
the zones of a page are unassigned manually as part of the gauge zone assignment process.
vZone BACK NEXT
% Engine Load
1 Coolant Temp
Intake Pressure
RPM
MPH
2 Timing Advance
º
To Next Page
