Page 61/63 UltraGauge™ EM User Manual www.ultra-gauge.com
Specifications
Voltage Range 10 to 16 Volts DC
Interface OBD II compliant
Protocols supported
CAN 11-bit, CAN 29-bit, J1850-VPM (GM), J1850-PWM (Ford), ISO 9141 (Chrysler and
foreign)
OBD II cable length ~ 6 foot
Operating temperature Range 0 ºF to 160 ºF
Storage temperature range -20 ºF to 160 ºF (Warranty is void beyond these limits)
Display LCD, LED backlight, Thermally compensated
Dimensions
3.43” Wide x 2.14” Height x 0.50” Depth:
http://ultra-gauge.com/ultragauge/support/dimensions.jpg
Power ~1W with display active, less than 1/4 watt with display off
Document Revision History
Doc Revision Date Detail
1.0 3/1/2019 First document release for EM Plus V1.4c
