YK10-0015-DI-002-03
v
Installation and storage
WARNING
●This product is packed with the wooden frame. Please ask the special
agency for dismantling it.
Advise the dismantling agent to wear leather gloves and use
appropriate tools such as pinch bar as they have a risk of cutting the
hand by nail or chip.
●Give the instruction them further to use the unloading machinery such
as crane to take out the product of the wooded frame, lift it up with its
top eyebolt and transfer it on lifting. Check the eyebolt whether it has
no error before use.
●Only the technically entitled person should be in charge of conducting
the unloading operation and operating the unloading machinery.
●There is a risk that the pump might drop or lay down when attempted
unreasonable operation or machinery setup was not sufficient. You
are strictly restricted to enter beneath the pump.
Transfer
WARNING
●You have a risk of giving damage to your back as the load larger than
safety standard shall be required to transfer the product.
PMB-040C：970kg (Without Motor)
PMB-060C:1100kg (Without Motor)
Be sure to use the loading machinery (such as mobile crane) to lift up
the Pump or load it on the pallet and fix it with Jack and run the Pallet
truck for its transfer.
●Never try to enter beneath the pump unit when lifted it up. Use the
accessory eyebolt to load/unload the unit.
●Do not put the folk of the fork lift or the like in the pump bottom
(exhaust outlet) to lift it.
●Note to purge the oil to transfer the pump. If forced to transfer
remaining the oil, be sure to keep the pump horizontal.
Do not tilt the pump 10 degree or more while you charge the oil. The oil
might run into the casing.
Countermeasure to the earthquake
WARNING
●There is a risk that the pump lays down or slides and breaks peripheral
units if it was not correctly fixed. Be sure to give allowances to the
vacuum piping, cooling water piping and electric cables so that they
absorber vibrations to prevent them from breaking and/or dismantling.
To Next Page
