Communica
tion & Control So
ftware for
UTD20
25
_30
25
Series Oscilloscopes
User
Manual
3.3
GPIB interface controls
The GPIB port is a dedicated interface module of
UTD30
25
Series Digital Storage Oscilloscopes. After installing
the communication
and control software, you can carry out system operation and control your oscilloscope
through the GPIB interface. You can create an automatic testing system simply, quickly and efficiently, and carry
out testing and measuring.
With the optional UT
-
M02 e
xtension
module, you can operate your
UTD30
25
oscilloscope through the GPIB
interface as follows
:
1.
Select “GPIB” in the equipment selection option on the real
-
time control panel.
2.
When “GPIB” is selected, the dialog box in Fig 3
-
6 will pop up.
Fig 3
-
6
Enter the GPIB device address in this box (range
: 1
-
30). The GPIB device addresses set in the software and the
communicated oscilloscope must be the same, otherwise communication between the
oscilloscope and the
software cannot be established.
Access sub
-
menu page 3 by pressing [UTILITY]

GPIB on the oscilloscope control panel for GPIB device
address setup.
There must not be two identical GPIB device addresses on one GPIB main line.
3.
F
or other operation instructions refer to steps 2 and 3 for “
USB interface controls” in this chapter.
Note :
When using the GPIB interface, the “transmission interface” feature is disabled.
