UniCarriers 1F1 - Mast - 1 F2 3.5 - 3.6 Ton (Cushion)

189
MAST - 1F2 3.3 TON (CUSHION)
Mast Name
Maximum Fork Height
in (mm)
Free Lift
without
Backrest
in (mm)
Tilt Angle
Forward/Backward
Overall Height
Lowered Mast Position
in (mm)
Extended Mast Position
in (mm)
Top of OHG Mast (OHL) With Backrest Without Backrest
TWO STAGE
(Wide View 2H)
2H280 110 (2800) 7.1 (180) 5/10 82.1 (2085) 76.8 (1955) Not Available
2H310 122 (3100) 7.1 (180) 5/10 82.1 (2085) 82.7 (2105) Not Available
2H350 138 (3500) 10.6 (265) 5/10 82.1 (2085) 92.9 (2360) Not Available
2H380 150 (3800) 10.6 (265) 5/10 82.1 (2085) 100.4 (2550) Not Available
2H430 169 (4300) 10.6 (265) 5/5 82.1 (2085) 110.2 (2800) Not Available
TWO STAGE
(Full Free 2F)
2F280 110 (2800) 50.0 (1270) 5/10 82.1 (2085) 76.9 (1955) Not Available
2F310 122 (3100) 55.9 (1415) 5/10 82.1 (2085) 82.8 (2105) Not Available
2F350 138 (3500) 66.1 (1675) 5/10 82.1 (2085) 93.0 (2365) Not Available
2F380 150 (3800) 73.6 (1865) 5/10 82.1 (2085) 100.5 (2555) Not Available
