UniCarriers 1F1 - Page 192

190
Mast Name
Maximum Fork Height
in (mm)
Free Lift
without
Backrest
in (mm)
Tilt Angle
Forward/Backward
Overall Height
Lowered Mast Position
in (mm)
Extended Mast Position
in (mm)
Top of OHG Mast (OHL) With Backrest Without Backrest
THREE STAGE
(Full Free 3F)
3F355 140 (3550) 45.1 (1145) 5/5 82.1 (2085) 70.9 (1805) Not Available
3F400 157 (4000) 51.0 (1295) 5/5 82.1 (2085) 76.9 (1955) Not Available
3F445 175 (4450) 56.9 (1445) 5/5 82.1 (2085) 82.8 (2105) Not Available
3F485 191 (4850) 62.2 (1575) 5/5 82.1 (2085) 88.1 (2240) Not Available
3F520 205 (5200) 67.1 (1700) 5/5 82.1 (2085) 93.0 (2365) Not Available
3F570 224 (5700) 74.6 (1890) 5/5 82.1 (2085) 100.5 (2555) Not Available
3F620 244 (6200) 84.4 (2140) 5/5 82.1 (2085) 110.3 (2805) Not Available
3F670 264 (6700) 94.3 (2395) 5/5 82.1 (2085) 120.2 (3055) Not Available
THREE STAGE
(Optiview 3V)
3V385 152 (3850) 45.7 (1160) 5/5 82.1 (2085) 76.9 (1955) Not Available
3V430 169 (4300) 51.6 (1310) 5/5 82.1 (2085) 82.8 (2105) Not Available
3V470 185 (4700) 57.5 (1460) 5/5 82.1 (2085) 88.1 (2240) Not Available
3V505 199 (5050) 62.8 (1595) 5/5 82.1 (2085) 93.0 (2365) Not Available
3V555 219 (5550) 67.7 (1715) 5/5 82.1 (2085) 100.5 (2555) Not Available
3V600 236 (6000) 75.2 (1910) 5/5 82.1 (2085) 110.3 (2805) Not Available
3V650 256 (6500) 85.0 (2155) 5/5 82.1 (2085) 120.2 (3055) Not Available
3V700 276 (7000) 94.9 (2410) 5/5 82.1 (2085) 130.0 (3305) Not Available
