Unifiller Systems Inc. Page 25 of 48 Manual Part No.: MINI
DOPOSITOR
Save Recipe Screen
The Save Recipe screen is accessed from the Load Recipe screen
by pressing the SAVE RECIPE button. This screen allows a
supervisor or higher security level to save recipes under different
names and numbers.
Note: Under no circumstances can the recipe be saved over the
Default Recipe # 0. The default recipe is used for troubleshooting
the machine and as a base point for creating new recipes. A
warning screen like the one shown on the right will appear in an
attempt to save over the Default Recipe # 0.
The Save Recipe screen contains the following functions and displays:
This button allows the operator to scroll through the recipes by increasing the
recipe number. The name of the recipe will appear in the Recipe Name To
Save dialog box below the number.
This button allows the operator to scroll through the recipes by decreasing
the recipe number. The name of the recipe will appear in the Recipe Name
To Save dialog box below the number.
This shows the number of the recipe that is currently selected by the – and +
buttons.
This field can also be pressed in order to enter the number by keypad.
This shows the name of the recipe that is currently selected in the Select
Recipe number field or the new recipe name that was recently entered.
This field must be pressed in order to enter a new recipe name by keypad.
The new name will only stay with the recipe if the SAVE button is pressed.
This button allows the operator to save the currently loaded recipe to the
number selected in the Select Recipe number field and uses the name
entered in the Recipe Name To Save field.
This button returns to the Load Recipe screen.
On the warning screen, this button returns to the Save Recipe screen.
