United Parachute Technologies Vector 3 - Setting Up the Pull-Out Deployment System

VECTOR3MANUAL
MAN‐004REV7.2507/20/2017
Thetoggleattachmentpointshouldbelocatedalongthesteeringlinessothatatfullflight,thetogglesareresting
againsttheguidering.Thisisimportanttoobtain propercanopyflight.Ifthetogglesare
mountedtoohighonthe
steeringlines,thecanopywillfly“inbrakes”andwillnotglideorlandcorrectly.Likewise,ifthetogglesaremounted
toolowonthesteeringlines,thecanopywillbecomelessresponsiveandthecanopypilotmaynotbeabletoapply
fullbrakes
orstallthecanopy.Thiscouldresultinflaringdifficultywhilelanding.

Thesesituationsarelikelytooccurwhenamain canopyishastilyswitchedfromonesetofriserstoanother.Ifthe
guideringsonbothsetsofrisersarenotlocatedthesamedistancefromtheconnectorlinks,
thesteeringtogglesmust
bemovedtoanotherlocationonthesteeringline.

Itisalsoimportanttosecurelyattachthetogglestothesteeringlines.Althoughusingtherearrisersmayadequately
controlsomecanopies,a“lost”togglecanbehazardousinsomecircumstances,andmayrequireacut
‐awayand
reservedeployment.

PROCEDURE
Thereare3methodsforattachingsteeringtogglestosteeringlines.
 MethodAisformaincanopieswithDacron(polyester)lines.
 MethodBisformaincanopieswithsmall‐diameterSpectra(Microline)thathaveafinger‐trappedandsewn
loopends.
 Method
Cisformaincanopieswithsmall‐diameterSpectra(Microline)thathaveonlyamarkforattachingthe
toggle.

METHODA—DACRONLINES
Afterthemaincanopyhasbeenproperlyattachedtotherisersandwhileitisstillonitsside,attachthetogglesby
performingthefollowingsteps:

1.Ensurethesteeringlinesarecorrectlyrouted(i.e.theyshouldnotwraparoundanysuspensionlines).Thisis
accomplishedbystartingatthetailofthecanopy.Tracetheuppersteeringlinesdowntothelowersteeringline.
Checkthattherighthandsteeringlinepassesthroughtheright
handrearslidergrommetandthelefthandsteering
linepassesthroughthelefthandrearslidergrommet.

2.Locatethemarkonthesteeringlinethat
indicatesthecorrecttogglelocation.

3.Threadthesteeringlinethroughtheguide
ringlocatedontheriser.

Verifythatthismark
isinthecorrectlocationby
referringtothemaincanopyowner’smanual.

NOTE
Verify that this mark is in the correct
location by referring to the main canopy
owner’smanual.
