United Parachute Technologies Vector 3 - Pre-Jump Inspection

VECTOR3MANUAL
MAN‐004REV7.2757/20/2017

PRE-JUMP INSPECTION
BEFOREJUMPINGTHEVECTOR3,CHECKTHEBOOTH3‐RINGRELEASE SYSTEMFORTHEFOLLOWING:
 Eachringpassesthroughonlyoneotherring.
 Thewhitelooppassesthroughonlythesmallring.
 Thewhitelooppassesthroughthegrommetontheendofthecablehousingwithouttwisting.

 Nothingpassesthroughthewhiteloopexcepttheyellowcutawaycable.
 TheBooth3‐Ringreleasehandleissecurelyfastenedtotheharness,andnocableisvisiblebetweenthe
handleandthecablehousings.Ifyourreleasehandlehasatendencytohideitself,orflipunder
yourmainlift
web,undotheVelcroandtwistthehandleinaclockwiserotation(whenwearingrig)sothehandlewillstick
outandslightlyforwardfora bettergrip.

WerecommendthatonlyUnitedParachuteTechnologies3‐RingrisersbeusedwiththeVector3harness/container.If
a
Vector3isfittedwith3‐RingrisersthatwerenotbuiltbyUnitedParachuteTechnologies,itisimportantthattheybe
checkedforproperconfiguration.ThesideviewaboveshowsacorrectlybuiltBooth3‐Ringriserattachedtothe
harnessringandputundermoderatetension.

NOTETHEFOLLOWING:

 Theringsoverlapeachotherandmaintainmetal‐to‐metalcontact.
 Theringsarealignedinparallelplanes.
 Thesmallestringisnotpulledsnugagainstthegrommet;thewhiteloopislongenoughtogiveitsomeplay.
 Thewhitelockingloopgoesstraightdown
throughthecenteroftherisergrommetonitswaytothecable
housingendfitting;itdoesnotextendpasttheedgeofthegrommetholeandthenturnbackupwards
towardsthehole.Ifyourriserconfigurationdoesnotmatchthisillustration, the3‐Ringreleasemightnot
function
correctly;contactariggerorUnitedParachuteTechnologiesifyouareunsureofthe3‐Ringriser
configuration.

Periodicmaintenanceofyour3‐ringreleasesystemiscoveredinsection6ofthismanual.

NOTE
RefertotheUnitedParachuteTechnologieswebsiteforthecorrectconfiguration.
http://unitedparachutetechnologies.com/
