INSTALLATION
TABLE OF CONTENTS
Step 1 – Checking Contents ................................................ 14
Step 2 – The Control Base .............................................. 15-17
Step 3 – Rough-In Wiring...................................................... 18
Step 4 – Attaching the Control to the Base ...................... 19
Step 5 – Mounting the Sensors .................................... 20-22
Step 6 – Electrical Connections to the Control............ 23-28
Powered Input Connection ............................ 23
Output Connections .................................. 24-25
Sensor Connections ........................................ 26
Unpowered Input Connections .................... 27
Temperature Resistance Chart ...................... 28
Step 7 – Testing the Wiring ............................................ 29-32
Test the Sensors .............................................. 29
Test the Power Supply .................................... 30
Test the Powered Demand Inputs ................ 30
Test the Outputs ........................................ 30-32
Step 8 – Completing the Installation .................................. 33
13
