INSTALLATION - STEP 4
ATTACHING THE CONTROL
TO THE BASE
1) Push the SYSTEMpro 311 control into the base you
mounted in Step 2
2) Slide the control down until it snaps firmly into place
(See fig. a)
19
INSTALLATION
INSTALLATION - Step 4 - Attaching the Control to the Base
a
