Uponor SYSTEMpro 311

INSTALLATION - STEP 2
THE CONTROL BASE
Removing the Control from the Base
Press down at the fingertip grips on top of the
front cover and pull out and down. (See fig. a)
Lift the front cover up and away from the control.
(See fig. b)
Loosen the screws at the front of the wiring cover.
(See fig. c)
The wiring cover pulls straight out from the wiring
chamber.
(See fig. d)
15
INSTALLATION
INSTALLATION - Step 2 - The Control Base
a
b
c
d
