22"
14
Most vehicles manufactured after September 1, 2002 are
equipped with LATCH (Lower Anchors and Tethers for
CHildren). Check your vehicle owner’s instruction book
to determine lower anchor compatible seating positions.
Vehicle Top Tether
Anchor Points
Vehicle Lower Anchor Points
NOTE: In order to use the rear center seating position with
lower anchor, the distance between the lower anchors
may be up to 22 in (55.9 cm) and the seating position
must be approved by the vehicle manufacturer. If spacing
between the lower anchors is greater than 22 in (55.9 cm)
or if the seating position is not approved by the vehicle
manufacturer then use the vehicle seat belt for installation.
Vehicle Compatibility – LATCH (Lower Anchors and Tethers for CHildren)
WARNING: DO NOT use the Lower Anchorage
System (LATCH) to attach this Child Restraint when
restraining a child weighing more than 40 lbs (18.1 kg)
for Rear-Facing installation and 45 lbs (20.4 kg) for
Forward-Facing installation.
