To Access Lower Anchor Connectors
1 To access Lower Anchor Connectors unsnap
fabric over front panel of Child Restraint.
Open the storage compartment and pull out
the Lower Anchor webbing and release the
Connector by pressing the red button on the
connector and pull to detach.
2 Lengthen the Lower Anchor Connector to
maximize length by pushing the Lower Anchor
Connector Adjuster Button and pulling to full
extension.
3 Loosen harness. (page 22)
4 Raise headrest to maximum height by pushing
down and pulling up on handle.
5 Unfasten the fabric and expose the
REAR-FACING or FORWARD-FACING
belt path.
6 Route Lower Anchor Connectors and Belt
under fabric seat pad from front of seat
aligning webbing with FORWARD-FACING
or REAR-FACING belt path. (See page 50 and 66)
Features Overview – LATCH Setup
