1 Open the lock-o door.
2 Route the vehicle lap belt through
the lock-o and through the REAR-
FACING BLUE belt path. Ensure there
is no twisting. Buckle.
3 Apply pressure into seating surface,
as shown, and pull up on excess belt
webbing to remove slack from the
lap belt.
4 Close the top section of the lock-o
door over lap belt
4A
. Close the
bottom section of the lock-o door
over the belt. Make sure you push the
bottom of the lock-o door all the
way down until you hear an audible
click.
Note: After the lock-o door is
closed, the Tightness Indicator
window will turn from RED to GREEN
4B
. If it does not, unbuckle and
return to step 3.
Rear-Facing Installation – Lap Belt Only Use
