1 Lock To connect Lower Anchor Connectors to Lower Anchors in vehicle,
push connector onto lower anchor until you hear a click. Pull to confirm
attachment.
Note: DO NOT push the red button.
2 Release To release Lower Anchor Connectors, press red button at end of
connector and pull to detach.
3 Store To store, fold Lower Anchor Connector and place into storage
compartment, tucking away excess webbing. Close door until firmly in place.
Snap fabric onto panel.
When not in use, the Lower Anchor Connectors MUST be properly
secured in the dedicated storage compartment under the front leg rest
portion of the Child Restraint.
WARNING: DO NOT use LATCH to attach this Child
Restraint when restraining a child weighing more than
40 lbs (18.1 kg) for Rear-Facing installation and
45 lbs (20.4 kg) for Forward-Facing installation. Please
refer to your vehicle owner’s manual for LATCH
information.
Features Overview – LATCH Use and Storage
