UPPAbaby Rove - Rear-Facing; Forward-Facing; Active Support Headrest Adjustment

1
2
26
The Active Support Headrest and harness provide
advanced Side Impact Protection that grows with
the child.
1 Loosen Harness (page 22).
2 Squeeze the Headrest Adjuster and move the headrest
up or down to the desired position
by pushing down
and pulling up on handle
. The harness will travel up or
down with the headrest.
Features Overview – Active Support Headrest Adjustment
1"1"
REAR-FACING FORWARD-FACING
Rear-facing: Minimum 1" (2.5 cm) gap between the child’s head
and top of headrest
A
. Harness should be at the
shoulders or 1-2 positions below
B
. Forward-facing: Harness
should be at the shoulders or 1-2 positions above
C
.
A
B
C
