1 Unsnap the front section of
fabric and slide Lower Anchor
Connectors under the fabric.
Unzip fabric panel on the seat.
Remove and feed through the
BLUE REAR-FACING Belt Path.
Close lower anchor connector
storage compartment and snap
fabric. (LATCH set up can be
found on page 50.)
2 Pull on the ring pull to open the
lock-o door
2A
. Route the belt
through the lock-o and through
the BLUE REAR-FACING belt path.
3 Push lower anchor connectors
onto the lower anchors located in
your vehicle seat bight (where your
cushion and back meet). There
should be an audible 'click' when
attachment takes place.
(3-4 illustrations on next page)
Rear-Facing Installation – LATCH Use
2A
