UPPAbaby Rove - Page 55

3 4
65
Proceed to page 54 for
Multi-Directional Tether usage.
53
Rear-Facing Installation – LATCH Use
4 Apply pressure into seating surface, as
shown, and pull up on the excess
lower anchor connector webbing
to remove any slack.
5 Close the top section of the lock-o
door over the lap/shoulder belt.
Second, close the bottom section of
the lock-o door over the belt.
Make sure you push the bottom of
the lock-o door all the way down
until you hear an audible click.
Note: After the lock-o door is
closed, the Tightness Indicator
window will turn from RED to GREEN
5A
. If it does not, disconnect and
return to step 2.
6 Using non-dominant hand, check
the belt path to ensure no more than
1" (2.5 cm) movement side-to-side
and front-to-back.
5A
