1 Open the lock-o door.
2 Ensuring there is no twisting in the vehicle
belt, route seat belt through the lock-o and
through the BLUE-REAR-FACING belt path.
Buckle.
3 While applying pressure into seating surface,
as shown, pull up on the vehicle shoulder
belt to tighten the belt. Holding the
shoulder belt taut to ensure no slack is
introduced back into the vehicle belt,
route through the lock-o (Steps 3-4
are on next page)
4 Close the top section of the lock-o door
over the lap/shoulder belt
4A
. Close the
bottom section of the lock-o door cover
over the belt. Make sure you push the
bottom of the lock-o door all the way
down until you hear an audible click
4A
.
Note: After the lock-o door is closed, the
Tightness Indicator window will turn from
RED to GREEN
4B
. If it does not, unbuckle
and return to step 3.
Rear-Facing Installation – Lap/Shoulder Belt Use
