Tighten Harness
1 Place harness over child and insert
buckle tongues into the buckle until a
“click” is heard. Pull up on the buckle
tongues to make sure they are locked
.
2 Pull up on the harness to remove
excess slack around the child’s legs. Pull
harness adjuster strap to tighten.
3 Close the chest clip and position at
armpit level.
4 Harness should be snug. Pinch harness
webbing at child’s shoulder (under
shoulder pad). If you can pinch
webbing, the harness is too loose and
should be tightened.
Note: Harness pads are optional.
Reference page 28 (Securing The
Child) for additional information.
Features Overview – Harness Use
