3
7
5
5A
6
4
69
5 Close the bottom section of the
lock-o door over the lap/shoulder
belt. Second, close the top section of
the lock-o door over the belt.
Make sure you push the bottom of the
lock-o door all the way down until you
hear an audible click .
Note: As pressure is applied, the
Tightness Indicator window will turn
from RED to GREEN
5A
.
6 Using non-dominant hand, check the
belt path to ensure no more than 1"
movement side-to-side and front-to-
back. It is possible to achieve a tight
installation even if the indicator is not
fully green.
7 Close the Lower Anchor Connector
Storage Compartment, snap fabric over
door and fasten the fabric panel along
the back.
Forward-Facing Installation – LATCH Use
