Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-32
ENGINE ASSEMBLY, AB46
KUBOTA DIESEL
68666-000
ITEM PART DESCRIPTION QTY.
ITEM PART DESCRIPTION QTY.
1 68694-000 ENGINE, KUBOTA DIESEL 1
2 68668-000 PUMP, VARIABLE DISPLACEMENT A10VG 1
3 67599-000 SOLENOID, THROTTLE 1
4 12733-099 HOSE, FUEL 5/16 LINE FT 4.5
5 20541-003 HOSE CLAMP 8
6 11937-003 FITTING 90° 6MJ-6FJX 2
7 27972-000 SOLENOID, STARTER RELAY 2
8 11252-006 SCREW HHC 1/4-20 X 3/4 12
9 68537-000 BRACKET, ENGINE MOUNT 2
10 12736-099 HOSE FUEL 3/16 LINE 2
11 68730-000 BRACKET, AIR CLEANER 1
12 REF FUEL FILTER, SPIN ON 1
13 68722-001 WELDMENT, MUFFLER SPACER 1
14 11941-015 FITTING STR 10MB 10MJ 1
15 67870-000 BRACKET, DIESEL FUEL FILTER 1
16 64423-000 INLINE SWIVEL - 1/4 1
17 11760-004 ROD END BEARING - 1/4-28 1
18 11934-019 FITTING 16MB-16MF 90° 1
19 11937-007 FITTING 90° 12FJX 12MJ 1
20 11240-007 WASHER, FLAT STD 7/16 12
21 63946-030 SCREW HHC M10 X 1.25 GR5 X 30MM 12
22 REF SCREW (SUPPLIED W/AIRCLEANER) 2
23 11252-004 SCREW, HHC 1/4-20 X 1/2 2
24 11934-027 FITTING 90° 8MB 4MJ 1
25 68812-000 FLANGE KIT 2
26 11941-016 FITTING STR 10MB 12MJ 1
27 68669-000 PUMP, GEAR TYPE 1
29 20541-013 HOSE CLAMP 4
30 11252-008 SCREW HHC 1/4-20UNC X 1 3
31 11240-004 WASHER FLAT STD 1/4 6
32 11238-004 WASHER SPLIT LOCK 1/2 2
33 11248-004 NUT HEX 1/4-20 ESNA 12
34 67617-050 KTR BELL HOUSING KIT D/F #0034 1
35 11256-010 SCREW HHC 1/2-13UNC X 1-1/4 2
36 11937-006 FITTING 90° 10FJX 10MJ 1
37 11253-010 SCREW HHC 5/16-18 X 1 1/4 4
38 REF AIR CLEANER, HOSES & CLAMPS 1
39 11240-006 WASHER FLAT STD 3/8 2
40 11238-005 WASHER 5/16 SPLIT LOCK 4
41 11273-005 NUT HEX 5/16 UNC JAM 4
43 69203-000 SUPPORT BRACKET 1
44 63961-025 SCREW M8 X 25mm LG 4
45 REF INLINE FILTER 1
46 63961-035 SCREW M8 X 35mm LG 2
47 63946-045 SCREW M10 X 45mm LG 2
48 63936-024 MUFFLER GASKET 1
49 20495-004 NUT HEX 1/4-28 UNF JAM 2
50 03142-001 FITTING 2MP 2FP 1
51 63945-001 OIL PRESSURE SWITCH 1
52 68770-000 EXHAUST TUBE 1
53 68747-000 INTAKE HOSE 1
54 13259-006 CLAMP 1
55 68779-000 VALVE CHECK 2
56 18084-003 TUBE 3/4 OD X 3/16W X .33 LG 1
57 18084-004 TUBE 3/4 OD X 3/16W X .205 LG 1
58 11240-005 WASHER FLAT STD 5/16 4
102 29601-021 CONN RING 12-10 GA. 3/8 DIA 5
103 29601-014 CONN RING 16-14 GA. 1/4 D 6
104 29610-002 CONN FORK 16-14 GA. #8 7
105 29616-002 CONN FEMALE PUSH 16-14 GA. 1/4 2
106 29452-099 WIRE 16 AWG BLK FT. 3
107 29453-099 WIRE 16 AWG ORG FT. 6.2
109 29480-099 WIRE 10 AWG RED FT. 3.8
110 68764-000 PLUG - CONNECTOR SEAL 10
111 29451-099 WIRE 16 AWG WHT FT 4.8
112 29454-099 WIRE 16 AWG RED FT 4.8
113 29601-020 CONN RING 12-10 GA 1/4 DIA 1
114 68762-001 SOCKET - CONTACT 7
115 68762-000 PIN - CONTACT 7
116 29457-099 WIRE 16 AWG GRN FT. 3.4
117 29479-099 WIRE 16 AWG WHT/BLK FT. 3.4
118 29450-099 WIRE 16 ASW BLU FT. 2.5
119 68761-001 DEUTSCH LOCKING WEDGE - CONN 1
120 68761-000 DEUTSCH LOCKING WEDGE - CONN 1
121 68760-000 DEUTSCH CONNECTOR -RECEPTACLE 1
122 68760-001 DEUTSH CONNECTOR -PLUG 1
123 29601-013 CONN RING 16-14 GA #10 2
124 29601-040 CONN RING 16-14 GA 5/16 DIA 2
