Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-22
UPPER BOOM LINKAGE ASSEMBLY
AB46
68322-000
ITEM PART DESCRIPTION QTY.
1 68497-000 TOP (OUTER) BOOM WELDMENT 1
2 68496-000 TOP (INNER) BOOM WELDMENT 1
3 68452-000 BOOM EXTEND CYLINDER 1
* 68452-010 SEAL KIT, EXTEND 1
4 68479-000 EXTENSION TUBE WELDMENT 1
5 68447-000 LEVELING TUBE WELDMENT 1
6 68453-001 JIB CYLINDER 1
* 68453-010 SEAL KIT, JIB CY. 1
7 68439-000 JIB BOOM WELDMENT 1
8 68438-000 SWINGING FRAME WELDMENT 1
9 68455-000 SLAVE CYLINDER 1
* 68455-010 SEAL KIT, SLAVE 1
10 68436-000 UPPER BEARING PAD CASSETTE 1
11 68435-000 LOWER BEARING PAD CASSETTE 1
12 68423-000 WEAR PAD 12
13 68492-000 EXT. TUBE MTG. BRACKET 1
14 68477-006 PIN, JIB ASSY. PIVOT 1
15 68473-000 PIN, SLAVE CYL. TRUNNION 2
16 68476-005 PIN, SLAVE CYL. ROD END 1
17 68476-006 PIN, JIB CYL. BASE 1
18 68476-003 PIN, BOOM PIVOT 2
19 68476-002 PIN, TELESCOPIC CYL. BASE 1
20 68476-004 PIN, JIB CYL. ROD END 1
21 68474-000 PIN, TELESCOPIC CYL. ROD END 1
22 62642-024 BUSHING, Ø 1.25 X.75 (20DU12) 2
24 62642-025 BUSHING, Ø 1.25 X 1.75 (20DU28) 8
25 62642-027 BUSHING, Ø 1.75 X .75 (28DU12) 2
26 62642-031 BUSHING, Ø 1.75 X 1.50 (28DU24) 2
27 62642-029 BUSHING, Ø 1.75 X 1.75 (28DU28) 2
28 11764-120 RETAINING RING, TRUARC #5100-125 2
29 65214-000 ROD END (PIN RETAINER) 4
31 11248-006 LOCKNUT, HEX. 3/8-16 UNC (ESNA) 2
32 11254-020 SCR, HHC 3/8-16 UNC X 2 1/2 2
33 12553-014 SCR, SOC HD. 1/4-20 UNC X 1 3/4 4
34 11822-006 SCR, BUTT. HD. 5/16-18 UNC X 3/4 8
35 14996-005 WASHER, FLAT 5/16 S.A.E. 30
36 11248-005 LOCKNUT, HEX. 5/16-18 UNC (ESNA) 12
37 11253-010 SCR, HHC. 5/16-18 X 1 1/4 6
38 62881-000 SWITCH, BALL DETENT 1
39 68508-000 PIN, LOWER 1
40 62642-040 BUSHING, Ø 2.50 X 1.00 (40DU16) 2
41 68470-000 PIVOT BRACKET WELDMENT 1
42 68691-022 CAT TRACK (22 LINKS) 1
43 REF. MOUNTING BRACKET (SET) 1
44 68701-099 WEAR STRIP, POLYETHYLENE 1.33 FT
45 11934-003 FITTING 6-4 4
46 11941-001 FITTING 6-4 2
47 65214-001 ROD END 1
48 11254-010 SCREW HHC 3/8-16UNC X 1 1/4 4
49 11238-006 WASHER, 3/8 SPLIT LOCK 5
50 11254-008 SCREW, HHC 3/8-16UNC X 1 1
51 11246-005 NUT, HEX ESNA 5/16-18UNC 2
52 61692-099 GROMMET (EDGE COVER) 1.5 FT
53 68778-000 VALVE, COUNTER BALANCE 3
54 11253-020 SCREW HHC 5/16-18 X 2 1/2 1
55 11248-005 NUT HEX ESNA 5/16-18UNC 1
56 68778-001 VALVE, COUNTER BALANCE 1
