Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-42
DRIVE VALVE BLOCK ASSEMBLY
AB46 - GAS/DIESEL
68347-000
ITEM PART DESCRIPTION QTY.
1 68546-000 VALVE BLOCK, DRIVE 1
2 68578-000 VALVE, POPPET 2 WAY ON/OFF 1
3 67649-000 VALVE, SPOOL 2 POS 3 WAY 2
4 63977-010 PLUG, EXPANDER “KOENIG” 1/4" 4
5 68579-000 VALVE, FLOW CONTROL 1
6 68596-000 VALVE, SPOOL 2 WAY N.O. 2
7 11935-001 ADAPTER, 45° EL 4MB-4MJ 2
8 11935-005 ADAPTER, 45° EL 10MB-8MJ 2
9 12004-008 PLUG, #8 S.A.E. 4
10 11941-020 ADAPTER, STR. 12MB-12MJ 2
11 12004-004 PLUG, #4 S.A.E. 1
12 05135-000 BALL, Ø 5/16" STEEL 1
13 13987-009 SPRING, Ø 1/4" X 19/32 1
14 11934-001 ADAPTER, 90° EL 4MB-4MJ90 1
15 11934-003 ADAPTER, 90° EL 6MB-4MJ 1
17 11941-004 FITTING, STR. 6MB-4MJ 1
18 11941-014 ADAPTER, STR. 10MB-8MJ 2
To Next Page
