Upright AB46 C User Manual

Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-54
CONTROLLER ASSEMBLY-PLATFORM
AB46 GAS
68329-001
ITEM PART DESCRIPTION QTY.
ITEM PART DESCRIPTION QTY.
* Not Shown
1 68589-001 BOX, ENCLOSURE 1
2 29939-003 LOCKNUT 3/4" NPT 4
3 29939-002 LOCKNUT 1/2" NPT 1
4 29925-000 CONNECTOR CABLE 1/2" NPT 1
5 29925-001 CONNECTOR CABLE 3/4" NPT 4
6 64446-003 EMERGENCY STOP BUTTON 1
7 67654-000 PUSH BUTTON FLUSH (BLACK) 1
8 68595-001 LENS, RED 1
9 11249-003 NUT, HEX 10-32 ESNA 2
10 12798-003 SWITCH, TOGGLE 2 POS 1
11 68800-000 LID WELDMENT, CONTROLLER I/C 1
12 11252-005 SCREW 1/4-20UNC X 5/8 5
13 68594-000 JOYSTICK - OPERATOR 4
14 68593-001 RHEOSTAT - CONTROLLER (12VOLT) 1
15 68795-000 JOYSTICK, P-Q 1
* 68795-010 HANDLE HALF, TRS, RIGHT 1
* 68795-011 HANDLE HALF, TRS, LEFT 1
* 68795-012 BOOT, M115, 0.31 SHAFT 1
* 68795-013 GASKET, M115 TRS GRIP 1
* 68795-014 SWITCH, XG3-Z1 1
* 68795-015 PUSH BUTTON, BLACK, SWITCH SPST 1
* 68795-016 SWITCH ACTUATOR,ROCKER SWCH GRIP 1
* 68795-017 CAP, ROCKER SWITCH GRIP 1
* 68795-018 ELECTRICAL ASSEMBLY, M115-1596 1
* 68795-019 ELEC ASSY, 500 ohm POTENTIOMETER 1
* 68795-020 PINION GEAR, M115 1
* 68795-021 SOCKET SET SCREW, 6-32 x 1/8, CUP 1
16 68819-000 KEYSWITCH & KEY 1
* 68807-010 KEY 1
17 68734-004 TERMINAL STRIP, 120V AC 1
18 68590-000 BASE INDICATOR (LAMP) 1
19 11826-012 SCREW RD HD 10-32 X 1-1/2 2
20 12798-004 TOGGLE SWITCH, 3 POS MOMENTARY 3
21 64417-001 FLANGE MOUNT 2
22 64443-001 CONTACT BLOCK, N.O. 1
23 68591-001 LAMP T-2-1/2 1
24 66805-012 CONTACT BLOCK, N.O./N.C. 8
25 11715-003 SCREW RD HD 6-32 X 3/8 4
26 29871-001 TOGGLE SWITCH, 3 POS. HOLD 1
28 64443-002 CONTACT BLOCK N.C. 2
29 67660-006 TERMINAL END 2
30 68698-001 TERMINAL BLOCK (TAN) 16
31 68698-002 TERMINAL BLOCK (BLUE) 3
32 68799-000 ANGLE, CONTROLLER 1
33 67662-001 RELAY SOCKET 4
34 67661-001 RELAY, SPDT 12 VOLT 4
35 67662-005 RETAINING CLIP & WIRE 4
36 11250-001 NUT HEX 6-32 4
37 67893-003 MOUNTING RAIL, DIN 8-1/4" 1
40 68897-099 GASKET, BLACK RUBBER 3.25 FT
41 68582-010 CIRCUIT BREAKER 10 AMP 1
42 68767-000 BRACKET, UPPER CONTROLLER 2
43 11708-004 SCREW 8-32 X 1/2 2
44 11248-002 NUT, HEX ESNA 8-32 UNC 2
45 11252-003 SCRW HHC 1/4-20UNC X 3/8" 2
46 68801-000 HAND SUPPORT WELDMENT 1
47 11248-004 NUT HEX ESNA 1/4-20UNC 7
48 14252-004 NUT SERT 1/4-20 1
49 66805-010 CONTACT BLOCK GE 1 N.O. 1
50 66805-011 CONTACT BLOCK GE 1 N.C. 1
51 68698-004 END CAP, CONTACT BLOCK 1
53 68698-000 TERMINAL BLOCK ORANGE 2
54 66516-005 PLUG, 11/16 FLUSH 1
55 68773-002 JUMPER 2 PIN 2
202 29454-099 WIRE 16GA RED | FT 21
203 29482-099 WIRE 16GA GREEN/WHT 3 FT
204 68735-099 WIRE 16GA BLACK/RED 5 FT
205 29452-099 WIRE 16GA BLACK 9.3 FT
206 29610-006 TERM FORK 18-14GA #6 60
207 29620-002 BUTT CONNECTOR 18-14GA 6
208 14914-001 CONN MALE PUSH INSULATED 3
209 29931-003 CONN FEMALE PUSH INSULATED 6
210 29451-099 WIRE 16GA WHITE 5.8 FT
211 29931-003 CONN FEMALE PUSH .25 (16-14GA) 12
212 29450-099 WIRE 16GA BLUE 4.1 FT
213 29825-002 DIODE 3 AMP 400V 9
214 29478-099 WIRE 16GA RED/BLACK 3.5 FT
215 29457-099 WIRE 16GA GREEN 1.5 FT
216 29616-001 CONN FEMALE PUSH .187 (16-14GA) 3
217 29360-099 WIRE 16GA ORANGE/GREEN 2 FT
218 29453-099 WIRE 16GA ORANGE 1.2 FT
219 29458-099 WIRE 16GA PURPLE 1.2 FT
220 29479-099 WIRE 16GA WHITE/BLACK 4 FT
221 29459-099 WIRE 16GA BLUE/WHITE .5 FT
222 29483-099 WIRE 16GA RED/WHITE 2.5 FT
223 29601-039 RING TERM 1
224 29455-099 WIRE 16GA BROWN 3 FT
226 68814-000 PIN TERMINAL 6
227 REF RECEPTACLE 1
228 29464-099 WIRE 14GA GREEN .5 FT
