Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-8
FINAL ASSEMBLY
AB46 DIESEL
68302-000
ITEM PART DESCRIPTION QTY.
1 68305-000 BASIC ASSY. AB46-D 1
2 68339-003 CONTROLLER INSTL-DSL, DOM 1
3 68335-002 LABEL KIT/INSTL-DSL, DOM 1
4 68336-001 HOSE KIT/INSTL-DSL NOT SHOWN 1
6 29945-014 LEVEL SENS P-Q DOM-I/C NOT SHOWN 1
7 68340-002 HYDRAULIC SCHEMATIC AB46 I.C. REF
8 68341-003 ELECTRIC SCHEMATIC AB46 DIESEL DOM REF
201 29610-006 TERMINAL, FORK 18-14 GA. #6 65
202 68814-000 TERMINAL, PIN 12
205 29496-099 WIRE, 2 COND. 16 GA. 5 FT
206 29496-099 WIRE, 2 COND. 16 GA, 37 FT
207 29496-099 WIRE, 2 COND. 16 GA. 24 FT
209 29498-099 WIRE, 4 COND. 16 GA. 11 FT
210 29447-099 WIRE, 3 COND. 16 GA. 11 FT
211 29447-099 WIRE, 3 COND. 16 GA. 13 FT
212 29433-099 CABLE, 24 COND. 18 GA. 63FT
214 29434-099 CABLE, 3-10 GA. / 9-14 GA. 63
215 29434-099 CABLE, 3-10 GA. / 9-14 GA. 63
216 29433-099 CABLE, 24 COND. 18 GA. 63
217 29433-099 CABLE, 24 COND. 18 GA. 11
301 29601-005 TERM, RING 18-22 GA. #10 22
302 29931-003 TERM, FEM. PUSH-ON 16-14 15
303 14914-001 TERM, MALE PUSH-ON 18-22 .25 3
402 29490-099 WIRE, 2 COND. 16 GA. SO. 8 FT
401 29440-099 WIRE, 3 COND. 12 GA. SO. 2 FT
403 29496-099 WIRE, 2 COND. 16 GA. 2 FT
