Upright AB46 C User Manual

Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-14
BASIC ASSEMBLY
AB46 GAS
68304-000
ITEM PART DESCRIPTION QTY.
1 68320-001 CHASSIS ASSY. AB46-GAS 1
2 68330-001 TURRET ASSY-GAS 1
3 68323-000 LOWER LINKAGE ASSY 1
4 68322-000 UPPER LINKAGE ASSY 1
5 68325-001 CAGE “B” ASSY 1
6 68703-000 HOSE GUARD 1
7 68704-000 HOSE GUARD (58") 2
8 68705-000 HOSE GUARD (68") 2
9 68706-000 HOSE CLAMP 14
10 68731-000 HOSE GUARD-JIB 1
11 68732-000 HOSE CLAMP-JIB 3
12 11248-004 NUT HEX ESNA 1/4-20 UNC 17
13 11240-004 WASHER 1/4 STD FLAT 17
BASIC ASSEMBLY
AB46 DIESEL
68305-000
ITEM PART DESCRIPTION QTY.
1 68320-002 CHASSIS ASSY. AB46-DSL 1
2 68330-002 TURRET ASSY-GAS 1
3 68323-000 LOWER LINKAGE ASSY 1
4 68322-000 UPPER LINKAGE ASSY 1
5 68325-001 CAGE “B” ASSY 1
6 68703-000 HOSE GUARD 1
7 68704-000 HOSE GUARD (58") 2
8 68705-000 HOSE GUARD (68") 2
9 68706-000 HOSE CLAMP 14
10 68731-000 HOSE GUARD-JIB 1
11 68732-000 HOSE CLAMP-JIB 3
12 11248-004 NUT HEX ESNA 1/4-20 UNC 17
13 11240-004 WASHER 1/4 STD FLAT 17
