Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-16
1 68381-000 CHASSIS WELDMENT (I/C) 1
2 11256-012 SCREW HHC 1/2-13UNC X 1-1/2 2
3 11239-008 WASHER FLAT ASTM 325 1/2"D 24
4 11248-008 LOCKNUT 1/2-13UNC ESNA 8
5 68370-000 SPINDLE WELDMENT (L.H.) 1
6 68370-001 SPINDLE WELDMENT (R.H.) 1
7 68368-000 STEERING PIVOT SHAFT 2
8 11257-040 SCR, HHC. 5/8-11 UNC X 5 2
9 11248-010 LOCKNUT, 5/8-11 UNC. (ESNA) 6
10 68456-000 STEERING CYLINDER 1
* 68456-010 SEAL KIT 1
11 68702-000 SCREW, 5/16" MODIFIED 2
12 11239-005 WASHER, 5/16" ASTM A-325 4
13 11740-014 ROLL PIN 1/2" DIA X 1 3/4" 2
14 11248-005 LOCKNUT, ESNA 5/16"-18UNC 2
15 68372-000 STEERING ARM 2
16 11256-014 SCREW, HHC 1/2-13UNC X 1 3/4 4
17 62642-033 BUSHING, Ø 1.25 X 1.00 (20DU16) 4
18 68380-000 STEERING PIN (SHORT) 2
19 68378-000 STEERING PIN (LONG) 2
20 11240-008 WASHER, FLAT 1/2" 2
21 11256-032 SCR, HHC. 1/2-13 UNC X 4 2
22 11249-008 LOCKNUT, 1/2-20 UNF (ESNA) 18
23 10092-014 THRUST WASHER, GARLOCK G 28 DU 2
24 68576-001 BUSHING, GARLOCK #GF4852-40 4
25 11788-001 SEAL, GARLOCK #71 X 6308 2
26 13888-224 O-RING, 1.75 I.D. X .125 SECT 2
27 68373-000 CAP, STEERING PIN 2
28 11253-006 SCR, HHC. 5/16-18 UNC X 3/4 4
29 68577-000 FRONT HUB ASSY. 2
* 68577-010 FRONT HUB REPAIR KIT 1
* 68577-008 STUD BOLTS 1
* 11469-005 WHEEL NUTS 1
30 67664-000 WHEEL/TIRE ASSY (RIGHT) 2
31 11297-010 BELLEVILLE WASHER, 5/8 DIA. 18
32 11469-005 LUG NUT 90° 9/16-18 UNF 24
33 11238-008 LOCKWASHER, SPLIT RING 1/2" 6
34 11240-014 WASHER FLAT 7/8" REF
35 11245-014 NUT HEX CASTLE 7/8-14UNF REF
36 11753-016 COTTER PIN 1/8" DIA. X 2" LG. REF
37 67664-001 WHEEL/TIRE ASSY (LEFT) 2
38 11252-008 SCREW, HHC 1/4-20 UNC X 1 6
39 11941-004 FITTING, STR. 6MB-4MJ 2
40 11254-022 SCREW, HHC 3/8-16 UNC X 2 3/4 5
44 68388-000 COVER PLATE 1
45 68575-000 MOTOR, HYDRAULIC 1
46 68571-000 DRIVE, WORM GEAR 1
47 14576-026 SCR, HHC. GR8 5/8-18UNF X 3 1/4 18
48 11941-038 FITTING 2
49 68757-001 LATCH 2
50 11715-004 SCREW MACH #6-32 X 1/2 4
51 68658-000 COVER, ENGINE COVER 1
52 11248-047 NUT #6-32 4
53 11240-001 WASHER #6 4
54 68386-001 DOOR WELDMENT R/H 1
55 68386-000 DOOR WELDMENT L/H 1
56 11248-004 NUT HEX ESNA 1/4-20 4
57 11252-016 SCREW HHC GR5 1/4-20 UNC 4
58 68680-007 FITTING, 90 DEG ELBOW 2
201 68381-000 CHASSIS WELDMENT (I/C) REF
202 11238-006 WASHER LOCK 3/8 SPLIT 3
203 11934-001 FITTING 90° 4MB 4MJ 1
204 20541-011 HOSE CLAMP 2
205 68709-000 HYDRAULIC TANK ASSY. 1
206 64275-034 BATTERY CABLE (POS) 2
207 68774-000 RUBBER SUPPORT 2
208 68729-001 HOSE RADIATOR 1
209 68729-000 HOSE RADIATOR 1
210 68347-000 VALVE BLOCK ASSY (DRIVE) 1
214 ** GASKET REF
216 68710-000 FUEL TANK ASSEMBLY 1
217 11240-006 WASHER 3/8 FLAT 14
218 11248-006 NUT HEX 3/8-16 ESNA 16
219 68661-000 ENGINE ASSY GAS 1
220 14252-004 NUT SERT 1/4-20 UNC 6
221 68570-000 PLANTARY DRIVE 2
* 68570-010 TORQUE HUB REPAIR KIT 1
* 68570-011 THRUST WASHER 1
222 68690-000 MOTOR, HYDRAULIC 2
* 68690-011 RETAINING RING 1
* 68690-012 LIP SEAL 1
* 68690-013 O-RING 1
* 68690-014 BEARING 1
* 68690-015 END CAP GASKET 1
* 68690-016 THRUST PLATE 1
* 68690-017 CYLINDER BLOCK KIT (SB-9410) 1
* 68690-018 VALVE PLATE 1
* 68690-019 NEEDLE BEARING 1
223 11934-010 FITTING 10MB-8MJ 90° 2
224 11934-007 FITTING 8MB-6MJ 90° 2
225 11935-001 FITTING 45° 4MBH 4MJ 1
226 68650-000 SHROUD, RADIATOR 1
227 29945-VAR LEVEL SENSOR (SEE FINAL ASSY) REF
228 11935-005 FITTING 45° 10MB-8MJ 2
229 11254-010 SCREW HHC 3/8-16 X 1 1/4 10
231 62299-002 BATTERY 12V DC 1
232 11715-004 SCREW RD HD # 6-32 X 1/2 2
233 11248-047 NUT # 6-32 HEX 2
234 29961-001 SEAL 1
235 68665-000 SPACER 3
236 68569-000 BRAKE, OSKO 2
237 11256-036 SCREW, HHC 1/2-13 UNC X 4 1/2 4
238 68676-000 RADIATOR 1
239 68675-000 BRACE WELDMENT 1
240 68549-000 BATTERY HOLD-DOWN BAR 1
241 12039-000 ROD, BATTERY HOLD-DOWN 2
242 11240-005 WASHER, 5/16" FLAT 2
243 11250-005 NUT HEX 5/16-18 UNC 2
244 * RADIATOR BOTTLE REF
245 68539-001 BOTTLE BRACKET 1
246 11252-006 SCREW, HHC 1/4-20UNC X 3/4 5
247 11248-004 NUT HEX ESNA 1/4-20 5
248 68751-000 GRILL 1
249 29961-000 INLET 1
250 19930-090 COUNTERWEIGHT 2
251 11257-020 SCREW HHC 5/8-11 UNC X 2 1/2 4
252 11240-010 WASHER 5/8 FLAT 4
253 003495-000 FITTING, STREET ELBOW 2
CHASSIS ASSEMBLY
AB46 GAS
68320-001
ITEM PART DESCRIPTION QTY.
ITEM PART DESCRIPTION QTY.
* Not Shown
