Upright AB46 C - Turret Assembly, Gas; Turret Assembly, Diesel

Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-24
TURRET ASSEMBLY
AB46 GAS
68330-001
ITEM PART DESCRIPTION QTY.
ITEM PART DESCRIPTION QTY.
TURRET ASSEMBLY
AB46 DIESEL
68330-002
1 68392-000 TURRET POST WELDMENT 1
2 68485-000 STOP WELDMENT 1
3 68319-000 SHIM, 16GA, REST PAD 4
4 68319-001 SHIM, 10GA, REST PAD 4
5 68660-000 REST PAD 2
6 11291-032 SCREW, HHC 5/8-11 X 4 GR 8 24
8 68478-000 TUBE, STL 1"O.D. X .120W X 3.10" LG 1
9 11248-012 NUT, HEX ESNA 3/4-10 ESNA 1
10 11240-012 WASHER 3/4 STL 2
11 68720-002 NEOPRENE SPRING CYLINDER-POLY. 1
12 14099-036 SCREW, HHC 3/4-10 X 4-1/2 1
14 68472-000 SHIM RING 1
15 11248-004 NUT, HEX ESNA 1/4-20 18
18 68656-000 COVER TRIM, GROUND CONTROL 1
19 68653-000 COUNTER WEIGHT, LEFT SIDE 1
20 68652-000 COUNTER WEIGHT, REAR 1
21 68654-000 COUNTER WEIGHT, RIGHT SIDE 1
22 68657-000 COVER TRIM, VALVE BLOCK 1
23 14099-012 SCREW HHC, 3/4-10UNC X 1-1/2 2
24 14918-020 SCREW HHC, 1-8UNC X 2-1/2 6
25 11239-012 WASHER FLAT ASTM 3/4" A325 2
26 11240-016 WASHER FLAT 1" STD 6
27 68328-001 LOWER CONTROL BOX-GAS 1
28 11297-010 BELLEVILLE WASHER 5/8 DIA 24
29 11240-004 WASHER, 1/4 FLAT STD 30
30 29958-001 HORN, 12 VOLT 1
31 68678-024 TUBING, POLYURETHANE 24" 2
32 13336-001 FITTING, GREASE 2
33 68679-003 FITTING, BULKHEAD 2
34 11252-006 SCREW, HHC 1/4-20 X 3/4 16
36 68348-001 VALVE BLOCK ASSY-I/C 1
38 REF DRIVE WORM GEAR (68571) REF
39 68660-001 REST PAD 1
40 68759-000 HINGE,TURRET COVER 2
41 11253-018 SCRW HHC GR5 5/16-18 X 1-1/2 1
42 11253-022 SCRW HHC GR5 5/16-18 X 2-3/4 2
43 68757-002 LATCH, SOUTHCO 2
44 61692-099 GROMMET MATERIAL 10FT
45 11253-012 SCRW HHC GR5 5/16-18 X 1-1/2 8
46 11248-005 NUT HEX 5/16-18 ESNA 12
47 14996-005 WASHER 5/16 FLAT SAE 22
48 11253-006 SCRW HHC GR5 5/16-18 X 3/4 5
49 11238-005 WASHER, SPLIT LOCK 5/16 4
50 11254-006 SCRW HHC GR5 3/8-16 UNC X 3/4 6
51 11238-006 WASHER, SPLIT LOCK 3/8 6
52 14996-006 WASHER, 3/8 FLAT SAE 6
54 68792-000 BRACKET 1
55 68793-000 BRACKET 1
1 68392-000 TURRET POST WELDMENT 1
2 68485-000 STOP WELDMENT 1
3 68319-000 SHIM, 16GA, REST PAD 4
4 68319-001 SHIM, 10GA, REST PAD 4
5 68660-000 REST PAD 2
6 11291-032 SCREW, HHC 5/8-11 X 4 GR 8 24
8 68478-000 TUBE, STL 1"O.D. X .120W X 3.10" LG 1
9 11248-012 NUT, HEX ESNA 3/4-10 ESNA 1
10 11240-012 WASHER 3/4 STL 2
11 68720-002 NEOPRENE SPRING CYLINDER-POLY. 1
12 14099-036 SCREW, HHC 3/4-10 X 4-1/2 1
14 68472-000 SHIM RING 1
15 11248-004 NUT, HEX ESNA 1/4-20 18
18 68656-000 COVER TRIM, GROUND CONTROL 1
19 68653-000 COUNTER WEIGHT, LEFT SIDE 1
20 68652-000 COUNTER WEIGHT, REAR 1
21 68654-000 COUNTER WEIGHT, RIGHT SIDE 1
22 68657-000 COVER TRIM, VALVE BLOCK 1
23 14099-012 SCREW HHC, 3/4-10UNC X 1-1/2 2
24 14918-020 SCREW HHC, 1-8UNC X 2-1/2 6
25 11239-012 WASHER FLAT ASTM 3/4" A325 2
26 11240-016 WASHER FLAT 1" STD 6
27 68328-002 LOWER CONTROL BOX-DIESEL 1
28 11297-010 BELLEVILLE WASHER 5/8 DIA 24
29 11240-004 WASHER, 1/4 FLAT STD 30
30 29958-001 HORN, 12 VOLT 1
31 68678-024 TUBING, POLYURETHANE 24" 2
32 13336-001 FITTING, GREASE 2
33 68679-003 FITTING, BULKHEAD 2
34 11252-006 SCREW, HHC 1/4-20 X 3/4 16
36 68348-001 VALVE BLOCK ASSY-I/C 1
38 REF DRIVE WORM GEAR (68571) REF
39 68660-001 REST PAD 1
40 68759-000 HINGE,TURRET COVER 2
41 11253-018 SCRW HHC GR5 5/16-18 X 1-1/2 1
42 11253-022 SCRW HHC GR5 5/16-18 X 2-3/4 2
43 68757-002 LATCH, SOUTHCO 2
44 61692-099 GROMMET MATERIAL 10FT
45 11253-012 SCRW HHC GR5 5/16-18 X 1-1/2 8
46 11248-005 NUT HEX 5/16-18 ESNA 12
47 14996-005 WASHER 5/16 FLAT SAE 22
48 11253-006 SCRW HHC GR5 5/16-18 X 3/4 5
49 11238-005 WASHER, SPLIT LOCK 5/16 4
50 11254-006 SCRW HHC GR5 3/8-16 UNC X 3/4 6
51 11238-006 WASHER, SPLIT LOCK 3/8 6
52 14996-006 WASHER, 3/8 FLAT SAE 6
54 68792-000 BRACKET 1
