Upright AB46 C User Manual

Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-38
1 67615-051 GASOLINE SHUT-OFF VALVE (LP-1) 1
4 67615-052 SOLENOID/FILTER (LP-2) 1
5 67615-055 REGULATOR / VAPORIZER (LP-5) 1
6 67615-056 FTG, 1/8 MPT - 1/4 HOSE BARB 1
7 67615-057 FTG, 90° STREET EL 1/4 PIPE 1
8 67615-058 FTG, 90° ELBOW 4 MPT - 6 MJ 2
9 67615-059 FTG, 90° 6 MPT - 5/16 HOSE BARB 2
10 67615-060 1/2" DIA. LP HOSE X 22" LG. 1
11 67615-061 1/4" DIA. HOSE X 23" LG. 1
12 67615-062 1/4" DIA. HOSE X 19" LG. 1
13 67615-063 5/16 DIA. HOSE X 15" LG. 10
14 67615-064 HOSE CLAMP 5/16" 10
15 67615-065 HOSE CLAMP 1/2" 2
17 67615-067 FTG, STR 8 MPT -1/2 HOSE BARB 1
19 67615-069 FTG, STR. 2 NPT - 5/16 HOSE BARB 2
20 67615-070 FEMALE ADAPTER (PROPANE TANK) 1
21 67615-073 FTG, STR 2MP-6MJ BRASS 1
22 67615-075 RELIEF VALVE 400 PSI 1
23 67615-074 FTG, 2-2-2 STR TEE BRASS 1
24 68805-000 BRACKET, PROPANE REGULATOR 1
25 67615-047 HOSE, HIGH PRESSURE SUPPLY 42" LG. 1
26 64189-001 DECAL, LIQUID WITHDRAWL 1
27 11248-006 LOCKNUT 3/8-16 UNC ESNA 4
28 11240-006 WASHER, 3/8" FLAT 4
29 68296-010 TANK MOUNTING BRACKET 1
30 27934-003 FUEL TANK, PROPANE 1
31 64421-000 DECAL 1
32 11252-006 SCRW, HHC 1/4-20 UNC X 3/4 2
33 11248-004 LOCKNUT, 1/4-20 UNC ESNA 2
34 67662-001 SOCKET, RELAY (SINGLE POLE) 1
35 68756-001 RELAY, SINGLE POLE 1
36 67662-005 RETAINER CLIP 1
37 29610-006 TERM, FORK 16-14 #6 9
38 14250-003 WELD STUD 3/8-16 X 1 4
DUAL FUEL CONVERSION KIT
AB46
68296-000
ITEM PART DESCRIPTION QTY.
