Upright AB46 C User Manual

Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-46
GROUND CONTROL BOX ASSEMBLY
AB 46 GAS/DIESEL
68328-001 GAS/68328-002 DIESEL
ITEM PART DESCRIPTION QTY. QTY.
GAS DIESEL
-001 -002
1 68717-000 BOX, GROUND CONTROL 1 1
2 67893-002 DIN RAIL, 14" LONG 2 2
3 29925-001 CORD GRIP, 3/4" 7 7
4 68734-004 TERMINAL STRIP (120 VOLT A.C.) 1 1
5 11709-010 SCREW, RD HD #10-24 UNC X 1 1/4 2 2
6 67662-001 SOCKET, RELAY SINGLE 23 23
9 67661-001 RELAY, SPDT 23 23
10 68698-000 BLOCK, TERMINAL (ORANGE) 3 3
11 68698-001 BLOCK, TERMINAL (TAN) 12 12
12 11248-047 NUT, ESNA 6-32 6 6
13 11240-001 WASHER, FLAT STD #6 6 6
14 11248-003 LOCKNUT, #10-24 UNC ESNA 2 2
15 67661-004 RELAY, 12VDC (FOUR POLE) 1 1
16 13283-002 CABLE MOUNT 18 18
17 29939-003 CONDUIT LOCKNUT 3/4" 7 7
18 68698-002 BLOCK, TERMINAL (BLUE) 12 12
19 67662-004 SOCKET, RELAY FOUR 1 1
20 11715-003 SCREW, RD HD MACH 6-32 X 1/2 6 6
21 67660-006 END BLOCK, TERMINAL 6 6
22 67893-001 DIN RAIL 4" LONG 1 1
23 67662-005 RETAINER CLIP, 1 POLE RELAY 23 22
24 68889-099 WEATHERSTRIP (FT) 4.5 4.5
25 67662-007 RETAINER CLIP, 4 POLE RELAY 1 1
26 14252-004 NUT SERT 1/4-20 UNC 2 2
27 68773-003 JUMPER 3 PIN 1 1
28 68773-002 JUMPER 2 PIN 1 1
29 68698-004 END, TERMINAL BLOCK (TAN) 2 2
201 68719-000 CONTROLLER BOX LID 1 1
202 64446-003 EMERGENCY STOP BUTTON 1 1
204 15752-000 HOUR METER 1 1
206 12798-004 TOGGLE SWITCH MOM DPDT 7 7
207 68582-010 CIRCUIT BREAKER 10 AMP 2 2
208 66516-008 PLUG, Ø .437 HEYCO 1 1
209 64443-002 CONTACT BLOCK N.C. 1 1
210 64443-001 CONTACT BLOCK N.O. 2 2
ITEM PART DESCRIPTION QTY. QTY.
GAS DIESEL
-001 -002
212 68588-001 KEY SELECTOR SWITCH 1 1
* 68807-010 KEY 1 1
213 08271-001 GUARD, TOGGLE SWITCH 7 7
215 64417-001 FLANGE, 3 CONTACT 2 2
216 67652-000 PUSH BUTTON, MOMENTARY GREEN 1 1
217 67654-000 PUSH BUTTON, MOMENTARY BLACK 1 1
218 29701-000 FUSE HOLDER 1 1
219 29704-025 FUSE 25A 1 1
221 66805-012 CONTACT BLOCK, 2 2
222 11709-004 SCRW MACH RD HD 10-24UNC X 1/2 4 4
223 11248-003 NUT HEX ESNA 10-24UNC 4 4
224 11821-005 SCRW BUTT HD SOC 1/4-20 X 5/8 LG 2 2
301 29452-099 WIRE, 16 GA. BLACK 13 FT 13 FT
302 29451-099 WIRE, 16 GA. WHITE 8 FT 8 FT
303 29454-099 WIRE, 16 GA. RED 30 FT 30 FT
304 29457-099 WIRE, 16 GA. GREEN 8.3 FT 8.3 FT
305 29453-099 WIRE, 16 GA. ORANGE 25FT 25 FT
306 29450-099 WIRE, 16 GA. BLUE 18FT 18 FT
307 29479-099 WIRE, 16 GA. WHITE/BLACK 10FT 10 FT
308 29478-099 WIRE, 16 GA. RED/BLACK 6.5FT 6.5 FT
309 05491-099 WIRE, 16 GA. GREEN/BLACK 5.3FT 5.3 FT
310 29477-099 WIRE, 16 GA. ORANGE/ BLACK 9.5FT 9.5 FT
311 29475-099 WIRE, 16 GA. BLUE/BLACK 4FT 4 FT
313 29483-099 WIRE, 16 GA. RED/WHITE 3.2FT 3.2 FT
314 29482-099 WIRE, 16 GA. GREEN/WHITE 3.3FT 3.3 FT
315 29459-099 WIRE, 16 GA. BLUE/WHITE 4.3FT 4.3 FT
316 29355-099 WIRE, 16 GA. BLACK/RED 5.5FT 5.5 FT
317 29356-099 WIRE, 16 GA. WHITE/RED 3.1FT 3.1 FT
318 29357-099 WIRE, 16 GA. ORANGE/RED 5.8FT 5.8 FT
319 29358-099 WIRE, 16 GA. BLUE/RED 4.2FT 4.2 FT
321 29360-099 WIRE, 16 GA. ORANGE/GREEN 3FT 3 FT
322 29825-002 DIODE 3AMP 400V 10 10
323 29610-002 CONN FORK TERM 16-14 94 132
324 29616-002 CONN F PUSH TERM 16-14 32 32
