Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-66
CAGE "B" ASSEMBLY
AB46
68325-001
ITEM PART DESCRIPTION QTY.
1 68500-001 CAGE “B” WELDMENT 1
2 68532-000 LIFT-UP GATE WELDMENT 1
3 68775-000 BASKET PIN WELDMENT 1
4 68457-000 CYLINDER, CAGE ROTATION 1
* 68457-010 SEAL KIT, CAGE ROTATE 1
5 68651-000 THRUST WASHER G32DU (MODIFIED) 1
6 65214-000 PIN RETAINER 1
7 63650-012 GAS SPRING 1
8 15936-010 SHOULDER BOLT 2
9 11248-005 LOCKNUT 2
10 11939-004 FITTING, 4MP-4MJ 2
11 11737-012 ROLLPIN 1/4" X 1-1/2" 1
12 11703-008 SCREW, HHC 1/4-20 X 1-1/2 1
13 11248-004 NUT HEX 1/4-20 3
14 11254-008 SCREW HHC 3/8-16 X 1 1
16 11821-005 SCREW BUTTON HD 1/4-20 UNC X 5/8 2
17 68277-000 LATCH ROTARY 1
18 68806-000 STRIKER WELDMENT 1
19 11709-004 SCREW RND HD 10-24 UNC X 1/2 2
20 68778-000 VALVE COUNTERBALANCE (550 PSI) 2
21 11238-006 LOCKWASHER 3/8 SPLIT 1
22 15936-005 SHOULDER BOLT 3/8 X 5/8 LG 2
23 11248-005 NUT, ESNA 5/16-18 2
