Upright AB46 C User Manual

LABEL KIT, AB46
GAS
68335-001
ITEM PART DESCRIPTION QTY.
LABEL KIT, AB46
DIESEL
68335-002
ITEM PART DESCRIPTION QTY.
2 061205-002 NAME PLATE / BOOM 1
3 065368-000 TACK 4
5 066552-000 LABEL EXPLOSIVE GAS 1
6 005221-000 LABEL BATTERY LEVEL 1
7 066555-000 LABEL LIMIT SWITCH 2
8 066556-000 LABEL PINCH POINT 2
9 066553-001 LABEL PINCH POINT 5
10 060197-000 LABEL HYDRAULIC FLUID 1
12 064166-000 LABEL UNLEADED FUEL 1
13 010076-000 MANUAL CASE 1
14 010076-001 LABEL ATTENTION 1
15 068342-001 USER MANUAL DOM I/C 1
16 060565-000 ANSI MANUAL 1
17 011248-004 NUT HEX ESNA 1/4-20UNC 4
18 011252-008 SCREW HHC X 1/4-20 X 1 4
19 062557-012 MAX LOAD 500 Lb / 225 Kg 2
22 064444-000 LABEL USA 1
23 066554-000 LABEL BEFORE OPERATION 3
24 068641-000 LABEL WARNING BRAKE RELEASE-I/C 1
25 068586-010 LABEL UPPER CONTROLS I/C 1
27 068587-010 LABEL LOWER CONTROLS 1
28 066562-001 TIRE PSI 4
30 066568-000 LABEL CRUSHING HAZARD 2
32 068632-000 LABEL HOLD DOWN 4
33 068633-000 LABEL READ & UNDERSTAND 1
34 068635-000 LABEL HARNESS POINT 2
35 068637-000 LABEL ARROW YELLOW 2
36 068637-001 LABEL ARROW ORANGE 2
37 066553-004 LABEL PINCH POINT 4
38 068638-000 LABEL EMERGENCY LOWER 1
39 068639-000 LABEL POWER TO PLATFORM 1
40 068634-001 LABEL AB46 2
41 061683-005 LABEL UPRIGHT 5
43 061683-007 LABEL UPRIGHT 1
48 068649-000 LABEL, CAUTION- RAISE JIB BOOM 1
2 061205-002 NAME PLATE / BOOM 1
3 065368-000 TACK 4
5 066552-000 LABEL EXPLOSIVE GAS 1
6 005221-000 LABEL BATTERY LEVEL 1
7 066555-000 LABEL LIMIT SWITCH 2
8 066556-000 LABEL PINCH POINT 2
9 066553-001 LABEL PINCH POINT 5
10 060197-000 LABEL HYDRAULIC FLUID 1
11 027898-000 LABEL DIESEL FUEL 1
13 010076-000 MANUAL CASE 1
14 010076-001 LABEL ATTENTION 1
15 068342-001 USER MANUAL DOM I/C 1
16 060565-000 ANSI MANUAL 1
17 011248-004 NUT HEX ESNA 1/4-20UNC 4
18 011252-008 SCREW HHC X 1/4-20 X 1 4
19 062557-012 MAX LOAD 500 Lb / 225 Kg 2
22 064444-000 LABEL USA 1
23 066554-000 LABEL BEFORE OPERATION 3
24 068641-000 LABEL WARNING BRAKE RELEASE-I/C 1
25 068586-010 LABEL UPPER CONTROLS I/C 1
27 068587-010 LABEL LOWER CONTROLS 1
28 066562-001 TIRE PSI 4
30 066568-000 LABEL CRUSHING HAZARD 2
32 068632-000 LABEL HOLD DOWN 4
33 068633-000 LABEL READ & UNDERSTAND 1
34 068635-000 LABEL HARNESS POINT 2
35 068637-000 LABEL ARROW YELLOW 2
36 068637-001 LABEL ARROW ORANGE 2
37 066553-004 LABEL PINCH POINT 4
38 068638-000 LABEL EMERGENCY LOWER 1
39 068639-000 LABEL POWER TO PLATFORM 1
40 068634-001 LABEL AB46 2
41 061683-005 LABEL UPRIGHT 5
43 061683-007 LABEL UPRIGHT 1
48 068649-000 LABEL, CAUTION- RAISE JIB BOOM 1
Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-70
