Upright AB46 C User Manual

Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-72
1 66817-000 STROBE MOUNT WELDMENT 2
2 12848-004 FLASHING STROBE LIGHT 2
3 66807-000 HORN 1
4 11258-008 SCR. HHC 3/4-10 UNC X 1 1
5 11238-016 WASHER, SPLIT LOCK 1
6 29496-099 WIRE, C COND. 16 GA. 8 FT
7 11709-004 SCREW # 10-24 UNC X 1/2" LG 4
8 11248-003 LOCKNUT # 10-24 UNC ESNA 4
9 11252-006 SCREW, HHC 1/4-20UNC X 3/4" LG. 1
10 11239-004 LOCKWASHER, 1/4" SPLIT RING 1
11 11240-012 FLATWASHER STD 3/4" 2
MOTION ALARM/FLASHING BEACON
OPTION - AB46
68294-000
ITEM PART DESCRIPTION QTY.
