Upright SL26 Series - Operation and Specification

2. Operation and Specification
2-3
2. Operation and Specification
2.1 I NTRODUCTION
G ENERAL D ESCRIPTION
Figure 1: SL26/30 SL Series
1. Platform
2. Elevating Assembly
3. Chassis
4. Power Module
5. Control Module
6. Platform Controls
7. Manual Case
8. Chassis Controls
9. Hydraulic Fluid Reservoir
WARNING
!
!
DO NOT use the maintenance platform without guardrails properly assembled and in place
