Upright SL26 Series User Manual

6-20
6. Illustrated Part List
Hydraulic Assembly
505507-000
Complete Hose Kit : 508084-000
ITEM PART DESCRIPTION QTY.
1 503954-000 HOSE, SUCTION 1
2 503955-000 HOSE, PUMP - PUMP TEE 1
3 503956-000 HOSE, PUMP TEE - MANIFOLD 1
4 503957-000 HOSE, RETURN (MANIFOLD - FILTER) 1
5 503958-000 HOSE, RETURN (FILTER - TANK) 1
6 503959-000 HOSE, MANIFOLD - FR TOP LH MOTOR 1
7 503960-000 HOSE, MANIFOLD - FR BOT RH MOTOR 1
8 503961-000 HOSE, FR LH MOTOR - FR RH MOTOR 1
9 503962-000 HOSE, MANIFOLD - REAR TOP LH MOTOR 1
10 503963-000 HOSE, MANIFOLD - REAR BOT RH MOTOR 1
11 503964-000 HOSE, R LH MOTOR - R RH MOTOR 1
12 503965-000 HOSE, FR LH MOTOR DRAIN - TEE 1
13 503966-000 HOSE, FR RH MOTOR DRAIN - TEE 1
14 503967-000 HOSE, FR MOTOR DRAIN TEE - TANK 1
15 503968-000 HOSE, R LH MOTOR DRAIN - TEE 1
16 503969-000 HOSE, R RH MOTOR DRAIN - TEE 1
17 503970-000 HOSE, R MOTOR DRAIN TEE - TANK 1
18 503977-000 HOSE, LH BRAKE - TEE (REAR MOTOR) 1
19 503978-000 HOSE, RH BRAKE - TEE (REAR MOTOR) 1
20 503797-000 HOSE, BRAKE TEE - MANIFOLD 1
21 503971-000 HOSE, MANIFOLD - STEERING CYL 2
22 503972-000 HOSE, MANIFOLD - LIFT CYL 1
23 503973-000 HOSE, LIFT CYL - TANK (RETURN) 1
24 503974-000 HOSE, PUMP TEE - AXLE FLOAT 1
25 503975-000 HOSE, AXLE FLOAT - TANK (RETURN) 1
26 503976-000 HOSE, MANIFOLD TO TILT (FORE / AFT) 2
27 503976-000 HOSE, MANIFOLD TO TILT (LEFT / RIGHT) 2
28 503990-000 HYDRAULIC TANK 1
29 057107-001 FILTER & HEAD 1
30 503953-000 PUMP (PTO DRIVEN) FOR PERKINS 403c11 1
31 505555-000 MANIFOLD BLOCK 1
32 064346-100 CYLINDER, AXLE FLOAT 1
33 064345-100 CYLINDER, TILT 2
34 063905-101 CYLINDER, STEER 1
35 063904-101 CYLINDER, LIFT 1
36 505201-000 REAR MOTORS 2
37 505202-000 FRONT MOTORS 2
