Upright SL26 Series User Manual

6-9
6. Illustrated Part List
Platform Assembly (Slide-out Section)
SL26SL ~ 064617-002
ITEM PART DESCRIPTION QTY.
1 06785-000 SIDE RAIL 2
2 ~ ~ ~
3 064778-000 FRONT RAIL 1
4 064763-000 DECK WELDMENT 1
5 064761-000 FLOOR (ALUMINIUM) 1
6 063727-000 BLOCK 4
7 064233-000 WHEEL (narrow) 4
8 064234-000 WHEEL (wide) 2
9 064235-000 WASHER 4
10 064776-000 TUBE, RAIL SUPPORT 2
11 064425-000 SLIDE BRACKET 4
12 063990-003 AXLE 2
13 064249-000 BUSHING (spanner) 2
14 064256-000 BEARING STRIP 1
15 064795-000 GUSSET PLATE 2
16 064267-000 BUMPER PAD 4
17 003570-001 RETAINING PIN ASSEMBLY 2
18 064774-000 ROLLER BRACKET 2
19 064769-001 R.H HANDLE 1
20 064769-002 L.H HANDLE 1
21 064773-000 HANDLE BRACKET 2
22 026553-008 POP RIVET - 3/16DIA 1/2-5/8 GRIP 12
23 026553-002 POP RIVET - 3/16DIA 1/8-1/4 GRIP 30
24 011240-004 FLAT WASHER 1/4 STD 22
25 064240-001 BUSHING 2
26 011254-018 SCREW - CAP 3/8-16 X 2 1/4 4
27 011254-032 SCREW - CAP 3/8-16 X 4 2
28 011254-010 SCREW - CAP 3/8-16 X 1 1/4 10
29 067685-000 SPACER 2
30 011248-004 LOCKNUT - 1/4-20 22
31 011252-014 SCREW - 1/4-20 UNC HEX HD X 1 3/4 10
32 011248-006 LOCKNUT - 3/8-16 26
33 011240-006 FLAT WASHER 3/8 STD 12
34 064775-000 FRONT ANGLE 2
35 ~ ~ ~
36 ~ ~ ~
37 011240-002 WASHER #8 6
38 064247-000 GUIDE SLIDE 3
39 011254-020 SCREW - CAP 3/8-16 X 2 1/2 6
40 011252-016 SCREW - CAP 1/4-20 X 2 4
41 011252-006 SCREW - CAP 1/4-20 HEX HD X 3/4 2
42 066550-006 DECAL - DANGER 1
43 066551-003 DECAL - DANGER 1
44 ~ ~ ~
45 011254-008 SCREW - 3/8-16 HEX HD X 1 4
46 064688-001 BRACKET - TOEBOARD PIVOT RH 1
47 064688-002 BRACKET - TOEBOARD PIVOT LH 1
48 101251-001 DECAL - DANGER TIP OVER 1
