Introduction
114100-000R1 X26 Ultra Narrow - Operator Manual Page 3
I NTRODUCTION
This manual covers the X26 Ultra Narrow Aerial Work Platform. This manual must be stored on the
machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G ENERAL D ESCRIPTION
Figure 1:
X 26 Ultra Narrow
WARNING
!
!
DO NOT use the machine
if all guardrails are
not properly in place and secured
.
1. Platform Controls
2. Manual Case
3. Platform Extension
4. Platform
5. Elevating Assembly
6. Chassis
7. Batteries
8. Charger Outlet Plug
9. Chassis Controls
10. Emergency Lowering Valve Knob
11. Hydraulic Fluid Reservoir
2
3
5
6
7
8
1
9
4
11
10
Rear
Power Module
Control Module
