Troubleshooting
10-20 OPERATION GUIDE
Inside the Left Covers 1, 3 and 4
Follow the steps below to clear paper jams inside left cover 1, 3 or 4 when using the optional paper feeder.
1 Pull up left cover 1 lever and open the left cover 1.
2 Remove the paper.
If the paper tears, remove every loose scrap from
inside the machine.
3 Press the specified position to close left cover 1.
Duplex Unit
Follow the steps below to clear paper jams in the duplex unit.
1 Pull up left cover 1 lever and open the left cover.
To Next Page
